CNC Tool Bt-C Power Milling Chuck Collet Holder for CNC Machine

Product Categories

BT Tool Holder [43]
SK Tool Holder [39]
NT Tool Holder [36]
CATE Tool Holder [21]
HSK Tool Holder [14]
ER Collet [48]
Spanner Wrench [13]
CNC Pull Stud [17]
Revolving Centre [9]
Drill Chuck [6]
Clamping Nuts [8]

Jining Qinfeng Machinery Hardwae Co., Ltd.

Contact Now

CNC Tool Bt-C Power Milling Chuck Collet Holder for CNC Machine

Name: CNC Tool BtC Power Milling Chuck Collet Holder for CNC Machine
Brand: QFMH
Price: 8 USD

Wholesale CNC Tool Bt-C Power Milling Chuck Collet Holder for CNC Machine from china suppliers

Brand Name : QFMH

Model Number : BT30,BT40,BT50

Place of Origin : CHINA

MOQ : 10PCS

Price : USD 8/PCS

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000PCS/MONTH

Delivery Time : 5DAYS

Packaging Details : PLASTIC BOX

Application : CNC machining

Size : BT40

Clamping Method : Collet

Certificateion : ISO

Machine : Bt-C Power Milling Chuck

Shank Type : Bt-C

Coolant Through : Yes

Compatibility : Milling machines

Color : Black

Type : BT30/BT40/BT50

Product Weight : 1kg

Contact Now

Model NO.: Bt-C
Size: Bt-C
Type: Precision translational head
Certification: ISO 9001:2008, ISO 9001:2000, GS, CE
Surface Roughness: Less Than Ra0.15
Dynamic Balance: G6.3-8000-12000rpm
Transport Package: Plastic Box
Origin: China

Logo Printing: Without Logo Printing
Customized: Customized
Material: 20crmnti
Hardness: HRC55-60
Taper: 7:24
Trademark: Szlusun
Specification: BT
HS Code: 8207400000

CNC Tool Bt-C Power Milling Chuck Collet Holder for CNC Machine

Model(BT×C-L1)	d	D	D1
BT40×C16-86	16	50	44.45
BT40×C20-90	20	56
BT40×C20-100	20	56
BT40×C20-135	20	56
BT40×C25-100	25	63
BT40×C25-105	25	63
BT40×C32-100	32	70
BT40×C32-105	32	70
BT40×C32-135	32	70
BT40×C42-115	42	90
BT50×C20-100	20	56	69.85
BT50×C32-110	32	70
BT50×C32-150	32	70
BT50×C42-120	42	90
BT50×C42-150	42	90
BT50×C42-165	42	90

CNC Tool Bt-C Power Milling Chuck Collet Holder is a precision tool holder designed for use with CNC machines. It is used to securely hold cutting tools such as drills, end mills, and reamers in place during machining operations.
The collet holder is made from high-quality materials and features a BT-C interface that is compatible with a wide range of CNC machines. It is designed to provide maximum gripping force and accuracy, ensuring that the cutting tool remains securely in place during high-speed machining operations.
The collet holder features a unique design that allows for easy and quick tool changes, making it ideal for use in high-volume production environments. It is also highly durable and resistant to wear and tear, ensuring long-lasting performance and reliability.
Overall, the CNC Tool Bt-C Power Milling Chuck Collet Holder is an essential tool for any CNC machine operator looking to improve the accuracy and efficiency of their machining operations.

CNC Tool Bt-C Power Milling Chuck Collet Holder for CNC Machine

BT Power Milling Chuck is a type of tool holder used in milling machines. It is designed to securely hold milling cutters and other rotary cutting tools in place during machining operations.
The BT Power Milling Chuck is named after the BT (Berg Taper) standard, which specifies the dimensions and angles of the taper on the shank of the tool holder. This standard is widely used in Japan and other countries.
The BT Power Milling Chuck is designed to provide high rigidity and accuracy, which is essential for achieving precise and consistent results in milling operations. It is typically made from high-quality materials such as hardened steel or carbide.
One of the key features of the BT Power Milling Chuck is its ability to generate high clamping forces without damaging the tool or the workpiece. This is achieved through a combination of the taper design and the use of a high-precision collet or chuck mechanism.

Product detail display
CNC Tool Bt-C Power Milling Chuck Collet Holder for CNC Machine
Characteristic:
Default standard balancing G6.3-8000rpm,precision dynamic balancing G6.3-12000rpm;
Inner hole of the shank divide into 6 troughs to prevent the insert remove,increase the grasp force;
Ball bearing cage is made of special material,improve the endurance,enhance the grasp force;
Strong grasp force ,high centering accuracy, suit for heavy cutting.
