BT40-MTA2-60 Morse Taper Adapter CNC Tool Holder morse taper shank G2.5 milling tool holder
Morse Taper Adapter with BT CNC Tool Holder ,BT tool holders use metric thread pull stud. We have G6.3 rpm 12000-16000 and G2.5 rpm 18000-25000.BT-MTA Morse taper milling tool holder, suitable for clamping type DIN228-1A with flat tail Morse tool holder.Morse taper adapter suitable for clamping type DIN228-1A with flat tail Morse tool holder. high speed and high precision machining.
BT MTA Morse Taper Adapter Holder
1.Material :20CrMnTi
2.Hardness:HRC52-54
3.Runout:0.005mm
4.Cooling:AD;AD/B can be made by request.
5.Balancing:G6.3/15000 RPM
6.Usage:for holding tools with Morse taper shank and tang according to DIN228-1 form B
7.modle No.: BT30,BT40,BT50
8. Material: high quality carburized synthetic steel, black and fine grinding
9.ontact Surface: ≥85%
10. Standard:MAS 403
11. Taper Shank: Tolerance Level <AT3
12.Maximum beating: <0.005mm
13.Surface roughness: Ra <0.005 mm
14. Shank of the Morse Taper Collet chuck MTA1/MTA2/MTA3/MTA4/MTA5
MTB1/MTB2/MTB3/MTB4/MTB5
| Model | MT.NO. | L | d | Weight(kg) | |
| BT30-MTA1-45 | 1 | 45 | 25 | 0.43 | |
| BT30-MTA2-60 | 2 | 60 | 32 | 0.5 | |
| BT40-MTA1-45 | 1 | 45 | 25 | 1.02 | |
| BT40-MTA2-60 | 2 | 60 | 32 | 1.11 | |
| BT40-MTA3-75 | 3 | 75 | 40 | 1.15 | |
| BT40-MTA4-90 | 4 | 90 | 48 | 1.43 | |
| BT50-MTA1-45 | 1 | 45 | 25 | 3.6 | |
| BT50-MTA2-50 | 2 | 50 | 32 | 3.63 | |
| BT50-MTA2-60 | 2 | 60 | 32 | 3.64 | |
| BT50-MTA2-120 | 2 | 120 | 32 | 4.3 | |
| BT50-MTA3-65 | 3 | 65 | 40 | 4.2 | |
| BT50-MTA3-120 | 3 | 120 | 40 | 4.4 | |
| BT50-MTA3-135 | 3 | 135 | 40 | 4.46 | |
| BT50-MTA3-150 | 3 | 150 | 40 | 4.68 | |
| BT50-MTA4-85 | 4 | 85 | 48 | 3.75 | |
| BT50-MTA4-95 | 4 | 95 | 48 | 3.85 | |
| BT50-MTA4-105 | 4 | 105 | 63 | 5 | |
| BT50-MTA4-108 | 4 | 108 | 63 | 5.06 | |
| suitable for clamping type DIN228-1A with flat tail Morse tool holder | |
| |
BT MORSE TAPER ADAPTER Tool Holder ,BT Morse Taper Adapter ,BT tool holders use metric thread pull stud. We have G6.3 rpm 12000-16000 and G2.5 rpm 18000-25000.Tool pack , please lock the handle with sword and lock screw .BT Morse Taper Adapter ,Removing tool , first relax tensed screw 2-3laps , and then on his sword first part of the handle witha hammer to knock zhi, relax after contact, and loosening Screw m remove the tool, Can do dynamic balance test G6.3 G2.5.
Precision milling machine Collet Chuck Morse taper Adapter , suitable for clamping type DIN228-1A with flat tail Morse tool holder.high speed and high precision machining .Mechanical spindle and cutting tools and other accessories.High Precision BT shank Tool Holder ,balanced G6.3 or G2.5 For choose.BT-MTA milling lathe chuck morse taper adapter with tang, for holding tools with Morse taper shank and tang according to DIN228-1 form B.Mechanical spindle and cutting tools and other accessories.
